CBB61 450VAC 4uF 50/60Hz 4 Pins Air Conditioner Motor Run Capacitor OZ SELLER1
- Model Number:
-
CBB61
- Type:
-
Polypropylene Film Capacitor
- Place of Origin:
-
China
- Brand Name:
-
E-cool
- Package Type:
-
Through Hole
- Rated Voltage:
-
220-500VAC
- Operating Temperature:
-
40/70/21
- Application:
-
AC / Motor
- Capacitance tolerance:
-
5%
- Package:
-
Individual Box and Cartons and Pallets
- Product name:
-
CBB61 capacitors
- Warranty:
-
2~5years
- Application of Capacitor:
-
pump,motors and washing machines
- Shape:
-
Square
- Shipment method:
-
By Truck,By Sea and By Air
- Frequency:
-
50/60Hz
- Capacitance:
-
1-40μF
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 22X34X37 cm
- Single gross weight:
- 600.000 kg
- Package Type:
- Exporting Standard Packing. Can offer bulk packing,Individual box packing,then use pallet. TBA by clients.
- Picture Example:
-
- Lead Time :
Quantity(Pieces) 1 - 5000 5001 - 20000 20001 - 50000 >50000 Est. Time(days) 10 15 20 To be negotiated
Feature
1:Widely applied to starting and running of AC single-phase motors at 50Hz/60Hz frequency power
2:Self-healing property
3:High stability and reliability
4:widly used in fan for speed regulation
Technical Specification
| reference standards | GB/T 366.7.1(IEC60252-1) |
| Climatic category | 40/70/21 40/85/21 |
| class of operation | Class B(10000h) class C(3000h) |
| class of safety protection | P0 |
| voltage range | 200VAC~660VAC |
| capacitance range | 1-16uF |
| capacitance tolerance | +-5% |
| Dissipation factor | 20*10-4 (100HZ,20OC ) |
| Test voltage terminal to terminal UTT | 2Un for 2 seconds |
| Test voltage terminal to case UTC | (2Un+1000)VAC or 2000VAC -50Hz for 60seconds |
| Insulation Resistance | >=3000M uF(100Hz 20 oC,1min) |
Small size, small loss and excellent self-healing property.
Very small dissipation factor, small inherent temperature rise.
High insulation resistance.
Good capacitance stability.
Available for refrigertors, fans, electric pumps, washing machines, air exhaustors, air-conditioners,fluorescent lamps,daylight lamps,halogen lamps, high pressure sodium lamps,etc.
Our Services
More than 20 years' professional experience about motor run capacitor 450v 2.5uf kondensator cbb60 sh en60252 1
Many certificates,ISO,CE,,UL,CQC,TUV,RoHS,cUL,SGS,etc
Sample is free and welcome you to check its quality firstly
Any inquiries will be timely answered within 24 hours
Exporting Standard Packing.
Can offer bulk packing,Individual box packing,then use pallet. TBA by clients.
15 to 25 days delivery time, depends on your orders' quantity.
Exporting Standard Packing.
Can offer bulk packing,Individual box packing,then use pallet. TBA by clients.
15 to 25 days delivery time, depends on your orders' quantity.
More than 20 years' professional experience about motor run capacitor
Many certificates,ISO,CE,VDE,UL,CQC,TUV,RoHS,cUL,SGS,etc
Sample is free and welcome you to check its quality firstly
Any inquiries will be timely answered within 24 hours
Hangzhou E-Cool Co., Ltd. is since 2007, and specialized in the production of all types of AC motor capacitor, cbb60 capacitor, cbb61 capacitor, cbb65 capacitor, cbb80 capacitor, 250vac capacitor, 450vac capacitor, 1uf~180uf capacitor, 110vac~630vac capacitor, en60252 capacitor, P2 capacitor, S3 capacitor, explosion proof capacitor, sh capacitor, motor run capacitor, fan capacitor, ceiling fan capacitor, air conditioner capacitor, water pump capacitor, air compressor capacitor, washing machine capacitor, microwave capacitor, power capacitor, lighting capacitor, lamp capacitor, electrothermal capacitor, ignitor for lamp,EMI filter for washing machine, wire & cable for home appliance and industrial microwave oven equipment.
In order to achieve better quality capacitor products, we have passed ISO9001 in 2007, got UL, cUL, TUV, CE, CQC, RoHS, REACH certificates etc.
With our strict quality management system, we are able to ensure the high quality of our products. Therefore, our products are very popular in Southeast Asia, the Middle East, American and Europe. And we have built up a very good reputation among our customers. Furthermore, we can design products according to your special demands.
With our business principle of "honor the contract and keep our promise", we will always keep our customers in mind. We would like to trial produce all special types of capacitors and industrial microwaves for customers all over the world. We welcome to interested companies to visit our company or contact us for more information.
12-1501 Yangguangcheng, Lvting Road, Yuhang District, Hangzhou, Zhejiang Province, China
