CD60 330VAC Start Capacitor for Compressor Motor Start Capacitor for Heat Pumps Air Conditioner
Product Description
CD60 330VAC Start Capacitor for Compressor Motor Start Capacitor for Heat Pumps Air Conditioner
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
JKD
Model Number:
CD60
Type:
Aluminum Electrolytic Capacitors
Application:
AC / Motor, Pump, Compressor, Heating Pump
Package Type:
Surface Mount
Capacitance:
21-1536MFD
Rated Voltage:
110/125/165/220/250/330/350V
Operating Temperature:
40/65(70)/21
Start Capacitor:
Electrolytic Motor Start Capacitor
SupplyAbility
SupplyAbility:
20,0000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Exporting Standard Packing.
Can offer bulk packing,Individual box packing,Foam Packing,then use pallet.
TBD by clients.
Port
Ningbo/Shanghai/Tianjin/Dalian/Guangzhou
Lead Time :
10-20 days
Specifications
1.Used widely in single phase motors, air compressor, water pump,compressor and etc
2.High performance & Long life Capacitor.
3.work well even in high temperature
CD60-B MOTOR START CAPAClTORS
Main Feature:
1.Bakelite resin case
2.Voltages from 110V AC to 330V AC
3.UL Recognized Capacitors
Applicable Scope :
To start and run single phase motors in alternating current usage,
And it suit for single phase A.C. motors with frequency of 50/60Hz.
General Specifications:
Operating Temperature:-40~+65°C
Voltage Range:110~330V AC
Capacitance Range:21~1536μf
Capacitance Tolerance:+/-20%
Operate Frequency:50/60Hz
Case Size:8 Standard Size from
1 437”x2.750” ~2 562”x4.375”/36mm x 70mm~65mm x111mm
Termination:1/4 ” Quick Disconnect Terminals(Std.)
Performance Specification:Meets Requirements of ElA-463-A and IEC-60252-2 and GB/T 3667.2-2016
Product Description
CD60 start capacitor is developed and researched according to standard of American
Electronics Association (ANSI/EIA-463).The external case of the capacitor is made of
Bakelite resin plasticized which Character is not only good insulating resistance. strong resistance damaged but also protecting electro liquid as good sealed feature. It is popular
used for the super AC application as good life, higher degree of reliability and stability.
